i3system’s line scanning X-ray detector platform, XID-C15DP/XID-C24DC, is a high performance and cost effective solution for dental panoramic, cephalometric applications. i3system’s direct type sensor ensures the most sharp images among the current products in the market. XID series is designed for compact size and easy installation. High DQE(Direct Quant㎛ Efficiency) enables high performance at lower dose of X-ray. Introduction Indirect type X-ray detector uses the scintillator and the photo-diode(CCD or CMOS sensor) for conversion of the X-ray into the light and for taking images espectively. But the light scatters and goes extinct during it passes through the scintillator and reaches to the CCD or CMOS sensor. As a result, it is inevitable to get blurred image. In the mean time, XID C15DP, direct type detector, converts X-rays into electronic signals directly without conversion process of light. Because X-ray is not converted into light, it provides much sharper images than indirect type detector. XID C15DP is designed to compact for easy installation. It provides Gigabit Ethernet port on the detector for easy configuration. Instead of Gigabit Ethernet, camera link or optical interface can be provided according to requirements of users.

The X-BEAM TECH HXB Connectors, featuring expanded beam technology, hermaphroditic connection, rugged construction for field deployment have been designed for harsh environment applications such as military tactical communications, avionics, offshore systems, outside broadcast, mining and plant.

The expanded beam technology uses expanded and collimated beams to couple optical fibers without any contact. It could allow for optics to be used in areas that have been quite restrictive due to presence of damage or contamination at the fiber end. Hermaphroditic connector design enables fast deployment by daisy-chaining multiple cable segments. HXB series connectors also enable transfer of electrical signal or power using hybrid insert configuration.

Our clamping division manufactures parts to secure external lines and tubes to the landing gear fitting and oleo.

STERNA System accurately finds True North in virtually all terrains and regardless of the weather conditions. The performance of STERNA System is not disturbed by gear carried by its operator or if used next to heavy armored vehicles. It remains highly accurate even when deployed on reinforced concrete floors or in dense urban settings. STERNA System operates reliably even in GPS denied environments and does not require the operator to carry any support resources to determine True North. If your mission success depends on the highest level of accuracy and precision, there is no substitute for STERNA System.

The family of PBS TJ40 turbojet engines features a compact design and excellent thrust-to-weight ratio. The engines are available in several versions incl. the PBS TJ40-G2 with high electric power output. Its distinctive features include simple and compact design, low weight and plug & play solution (all components including ECU integrated in the engine body). The engine weighs only 3.6 kg and provides a maximum thrust of 425 N.

The VPX6-C6 which provides a full 6U OpenVPX(VITA65) is a Single Board Computer(SBC) that combines the power, versatility, cost-effectiveness of the 8th generation Intel mobile one-chip processor solution with the reliability. VPX6-C6 is based on the Intel i7-8665UE CPU that has quad cores running at 1.7GHz and providing a 32Gbytes of highbandwidth DDR4 SDRAM. Intel i7 processor includes an integrated Intel UHD 620 graphics engine, providing discrete GPU performance with OpenGL for graphics-intensive applications. For storage application VPX6-C6 provides the built-in 80GB SLC NVMe SSD solution via PCIe x4 lanes as well as the external SATA expansion through VPX site. The VPX6-C6 satisfies the demanding applications ranging from tactical aircraft to armoured vehicles to rugged industrial systems, with its rich complement of features and I/O including Intel Graphics, Integrated Platform Management Interface, Gigabit Ethernet, DIO, Serial channels, USB ports and more.

SAT-PRE establish emergency communication networks for communication-disrupted areas during natural disasters and catastrophes. SAT-PRE ensures communications between commands in deepest operational areas and also between team members. it maximized communication success in adverse terrain, weather and other terrible conditions. The rate of transfer success is over 90%. The implementation of various communication methods such as voice PTT, automatic location reporting, and specialized transmission and reception using satellites as we reflects the latest technology based on Iridium 2nd generation satellites. The mission control center's CL-700 receives information transmitted from the operational area SAT-PRE in real time for up to 1,000 units and shares on-site situations by linking with other systems.

◎DTP services We are able to accommodate the various needs of our clients. In addition to basic Word Processing, we provide sophisticated editing of documents using PC and Macintosh expertise to match the characteristics of documents, including multilingual typesetting, design and publication printing. ◎Electronic manuals ① A manual that enables users to access the contents they need easily and conveniently by running a booklet-type manual on a PC or mobile device. ② Format: PDF, CHM (html-based) and customization according to the customer's needs ③ Electronic Technical Manual (IETM) : The Interactive Electronic Technical Manual (IETM) is an electronic technical support system that constructs a vast number of technical documents in a digital electronic document system ④ Developing process : STEP 01 Basic design >STEP 02 Prototyping >STEP 03 Detailed design > STEP 04 Making ITEM > STEP 05 Training/Test > STEP 06 Operation
