- Operates by an internal pipeline open/close mechanism controlled by a solenoid valve - Relief plug: prevents malfunction due to internal pressure expansion - Manual discharge available via manual handle when power is OFF - Outputs an abnormal signal if the reference pressure drops due to extinguishing agent leakage

Phase shifter for Electrically Scanned Array Antenna

The X-BEAM TECH HXB Connectors, featuring expanded beam technology, hermaphroditic connection, rugged construction for field deployment have been designed for harsh environment applications such as military tactical communications, avionics, offshore systems, outside broadcast, mining and plant. The expanded beam technology uses expanded and collimated beams to couple optical fibers without any contact. It could allow for optics to be used in areas that have been quite restrictive due to presence of damage or contamination at the fiber end. Hermaphroditic connector design enables fast deployment by daisy-chaining multiple cable segments. HXB series connectors also enable transfer of electrical signal or power using hybrid insert configuration.

To guarantee maximum safety and reliability, our DA 30 features a brushless motor and a contactless wear-free position sensor. This means maximum service life with the greatest‐possible power delivery and its design prevents electromagnetic emissions (EMI) caused by brush sparking. The housing made of saltwater‐resistant aluminum is HART‐coat treated, meets the IP‐67 standard for water and dust sealing and provides an integrated Sub‐D connector (MIL spec. circular connector or cable gland on request). Brackets integrated in the housing for horizontal and vertical assembly. 8‐fold, ball‐bearing supported, steel gear train, drive shaft with ANSI multi‐tooth. The DA 30 series can be equipped with a standard PWM input (Pulse Width Modulation) that has two different interfaces: a differential, galvanic isolated interface (Opto‐Coupler) and a single‐ended interface with CMOS levels that is also used to program the servo parameters. It includes analog position feedback to detect the drive shaft position. A differential RS‐422 PWM interface can be chosen instead of the opto‐coupled interface. The DA 30 with digital serial command interface (RS‐485) receives its commands via a CRC secured protocol. It can return not only the shaft position in digital format, but also several diagnostic data such as the level of the supply voltage, current consumption and the temperature of the motor and electronics in digital form (optionally also the humidity within the actuator case). These kind of diagnostic capabilities help to determine the health state of the actuators before, during and after deployment.

Monitors abnormal engine operation based on digital and analog signals from the aircraft engine. It calculates engine life indices and detects engine malfunctions for generate a Pilot Fault List (PFL), which will stored in memory. When an engine failure is detected, it provides warning for display on the Central Maintenance Panel (CMP). Developed as a replacement for obsolete, achieving 60% cost competitiveness compared to equivalent products. - x1 MIL-STD-1553B - x16 Discrete Inout - x14 Discrete Output - x3 Analog Input - x1 RS-232 - Size: 283 x 265 x 89 (mm) - Weight : 4.1Kg - Environment : MIL-STD-810G - EMI/EMC : MIL-STD-461G - Power : MIL-STD-704F (28VDC, 25W)

To reduce aircraft development lead-time, Safran Engineering Services is specialized in quick design and engineering in full autonomy. Teams provide global loads for ground and flight maneuvers, follows the evolution of weight and center of gravity for aircraft components and support sales campaigns with weight & balance evaluation.

This hydraulic tool package product is an ultra-high-pressure tool product used to assemble and disassemble major parts that make up the engine, and has been supplied to domestic and overseas engine customers since our foundation. The composition consists of a hydraulic pump, a hydraulic jack, a hydraulic hose, and a coupler, and supplies one package per ship. The product model can be selected according to the required pressure for each engine type and model.

Frazier Aviation is part of the Boeing Preferred Supplier Inspection Delegation (PSID) Program and is required to maintain a quality performance level of 98%.
