Altimeter for Missile Application

The KX2-2046 is an X-band high-power MMIC amplifier fabricated on the GaN-on-SiC process. It operates from 8.0 – 10.5 GHz and typically provides 20W saturated output power with power-added efficiency of 46%. The KX2-2046 can support military and commercial radar systems. It is matched to 50Ω with integrated DC blocking capacitors on both RF input and output ports. The KX2-2046 is 100% DC and RF tested on-wafer. It is available in chip form. **Key Features** - Frequency Range: 8.0-11.5GHz - Small Signal Gain: 26dB - High Pout: 20W - High PAE: 46% - DC bias: Vd=28V @Idq=0.3A - Pulsed Vg: PW=100µs, DC=10% - Chip size: 2.95x1.66x0.1mm

Product Information Frequency signal generator for small target detection High-frequency resolution design and frequency conversion function using DDS method main performance Frequency: Ku-Band ~ Ka-Band Very Small Size, Pulse Mode Output Level: -5dBm min Spurious: -30dBc min Harmonic: -40dBc min Phase Noise: High Performance Frequency Sensibility: 50ppm max Port isolation: 50dBc Min Applicable fields Applicable to ultra-small guided weapon tower system and small radar system

We provide advanced Laser-wire Directed Energy Deposition (LW-DED) 3D printing service. Our capabilities include processing various aerospace-grade materials including titanium, niobium, and other specialized alloys, with unlimited scalability for critical aerospace component production and prototyping.

Our first drone design, the ZenaDrone 1000, is an intelligent unmanned aerial vehicle that incorporates machine learning software and artificial intelligence. It was originally created to revolutionize the farming sector, and has evolved into a multifunctional heavy-lift drone for different industries. The ZenaDrone 1000 comprises innovative software technology, compact hardware components and customizable functionalities designed for industrial uses in construction, agriculture, surveillance, military applications search and rescue, and environmental inspection. We recently launched our second commercial drone, the ZenaDrone IQ Square. The ZenaDrone IQ Square is a micro drone designed primarily for indoor use. It has autonomous inspection and monitoring functions and can self-regulate through integrated multiple sensors, cameras, and interconnectivity conduits. This drone has a sleeker, more portable design with superior video transmission and sensing systems for reliable aerial visual data. The advanced drone technology of ZenaDrone IQ Square is highly integrative to various industries for better performance through its convenient micro drone compact design. The ZenaDrone technology continuously adapts to the different needs of companies in various industries requiring customization of drone capabilities and drone attachments, to meet each client's individual business operation specifications.

Its compact and robust design, coupled with a choice of analog, digital, and digital RS-232 outputs, makes the DSP-3000 the most versatile fiber optic gyro available and an ideal solution for guidance and stabilization, low-cost IMUs, integrated GPS/INS, and AHRS. Highlights EMCORE’s mature all-fiber optical circuit for exceptionally low noise (ARW) EMCORE’s proprietary E•Core polarization-maintaining fiber Robust, modular design housed in a package roughly the same size as a deck of playing cards Technology Details DSP Technology EMCORE’s DSP electronics improve FOG performance in critical areas such as scale factor and bias vs. temperature, scale factor linearity, and maximum input rate. EMCORE’s exclusive DSP design is covered by multiple patents* and overcomes the limitations of analog signal processing, eliminating temperature-sensitive drift and rotation errors. *This product is covered by one or more patents, including U.S. Patent #6,429,939, “DSP Signal Processing for Open Loop Fiber Optic Sensors.” Feature Options Two Versatile Variants If you need a compact FOG with a powerful high-speed RS-422 interface with 1000 Hz asynchronous output, consider the DSP-3100 FOG. If you require a true RS-422 interface and a 1000 Hz synchronous output in a durable, shielded package, take a look at the DSP-3400.

Purposed for people carrying two or more radios (JTAC, LEADER, RTO, etc) Removable shoulder & waist straps can be adjusted to fit the end-user without removing the rack Attaching to select tactical plate carriers with the QASM buckle system or using stand-alone with H Harness Small 4-way stretch Tweave general purpose pouch (Qty.1) Magazine pouches for 5.56mm or 7.62mm mags (Qty. 2) PRC-152A or 148 radio pouches (Qty. 2) Removable antimicrobial/FR treated spacer mesh pad Compatibility : PICO-DSX, PICO-DS, PICO-MBAV, EPIC-FED, EPIC-LOC-MOL & EPIC-DSX Composition Material : 500D Cordura® + ARAMID / PV® Color : MC (MultiCam) BMC (Black MultiCam) BK (Black) RG (Ranger Green) CYT (Coyote Brown)

To date, we have experience producing more than 10,000 pieces and have the ability to produce an average of 500 molds per year.
