RFcore has been innovating MMIC solutions for phased array system pursuing more ease of use, higher performance, higher level of integration as well as lower cost. We believe that the most suitable way is exploiting properties of God gifted semiconductor Silicon and GaN. We aim at integrating all components of TRM for active phased array on single die and even multi-channel TRM too.

High impedance D-Sub connectors are designed to ground the outer shield of a twinax or quadrax contact directly to the shell of the connector. A multi-finger ground spring fixed around the shell provides a multi-point contact engagement that affords superior EMI shielding. The end result is an extremely low contact resistance when measured from the contact outer body to the connector flange, ensuring minimal RF noise and high durability of over 500 mating cycles.

EMCORE’s SDI170 IMU is designed as a performance-compatible inertial system that is form, fit, and functional with a legacy RLG-based IMU product, but with superior overall performance, versatility, and a significantly higher MTBF (Mean Time Before Failure) rating over ruggedized environments. The tactical performance of the SDI170 IMU is based on EMCORE’s mature, proven, dependable and accurate quartz MEMS inertial sensor technology in our SDI500 tactical-grade IMU. EMCORE’s quartz technology enables repeatable high-volume production of precisely machined sensor structures combined with the inherent large signal output and thermal stability of quartz materials. The SDI170 IMU is designed for demanding, mission-critical, rugged environments and ideal for continuous use applications with no wear-out components, highly linear accelerometer performance and longer life compared to competing alternatives. It is constructed with EMCORE’s latest generation quartz gyros, quartz accelerometers, and high-speed signal processing to achieve outstanding precision performance. The solid-state quartz sensors and hermetically sealed IMU construction provide reliable MTBF and a 20-year operating and storage life. Continuous Built-in Test (BIT), configurable communications protocols, electromagnetic interference (EMI) protection and flexible input power compatibility make the SDI170 IMU easy to use in a wide range of higher-order integrated commercial and defense system applications.

Leveraging industry’s leading MEMS technology to provide previously unheard of capabilities in angle random walk values (0.02°/√hr.) without loss of tactical grade levels across military environments, including 1°/hr. bias stability, the SDI500 is designed to achieve the demanding performance levels required in sophisticated systems applications. It is particularly suited for use by Integrators and OEMs, packaged in a highly miniaturized, cylindrical configuration with a volume of only 19 cubic inches. Boasting a 20-Year lifetime capability without requiring calibration and a MTBF of more than 100,000 hours, multiple output data formats and SDLC, RS232 and UART output interfaces are provided in this revolutionary IMU for optimized systems protocols.

Sung Jin’s Nano Miniature Connector is applied twist pin for low engagement and separation force. Nano Miniature connector has a .025 inch contact space, and #30AWG, #32AWG of wire sizes are accepted. Innovative contact system that allows current of 1AMP ensures excellent electrical performance and characteristics. Sung Jin C&T’s Nano D miniature connector is designed to meet MIL-DTL-32139 standards and guarantees excellent mating performance and environment.

Our XR-based aircraft maintenance simulator is officially certified by the Ministry of Land, Infrastructure and Transport (MOLIT) of South Korea for training and education. It provides specialized training environments for the A321, B737-MAX, and B737-800NG aircraft, featuring over 80 detailed modules—including procedures for engine removal, main landing gear installation, and more. This subscription-based simulator is fully compatible with smartphones, tablets, and wearable XR devices, enabling seamless access through a cloud-based web service. Users can train anytime, anywhere—perfect for both remote learning and remote maintenance scenarios. Compared to traditional classroom learning, the XR platform is 4 times more effective and requires only one-third the training time. It also improves user confidence in real-world technical applications by up to 275%. By transforming traditional paper manuals into immersive, interactive training environments, the simulator delivers the next generation of aircraft MRO education for both civil and defense sectors.

The RFcore Radar series are FMCW type radar and were developed to detect/track small air targets. The major difference between three models is detection performance. RX32B is fundamental model. RX128B have four times larger radar than RX32B. RX192A have six times larger radar then RX32B. The number of the product name means the number of antenna elements. All have compact and lightweight physical architecture that concentrates all the components required for radar, such as antenna, RF components and radar signal processor, in a small single housing. Transport can be carried in the carrier box and can be easily carried by one person. For installation, you can use a commercially available camera tripod. The weight is about 7.5kg (RX32B) and 15.9kg (RX128B), and the lower connection part is compatible with the tripod connection for the camera. Power supply requires 12VDC (RX32B) and 24VDC power (RX128B and RX192A). When using a battery, it is possible to connect a 12V battery or 24V battery to radars. Usage time may vary depending on the battery capacity. RFCORE recommended the constant power supply. Transfer of Status and BIT information and simple control of the RX32B, RX128B and RX192A are possible with a web browser using the Ethernet connection for authorized users. Using the terminal program provided with the radar, you can view the radar control and detected target information in real time. All RX Radar series’ Power Amp and Core Chip were designed using RFcore's own products.
