KJF designed and fabricated A320 Sharklet Moving Line

- Dimensions (L x W x H): 40 x 90 x 35 mm (receiver + antenna array) - Weight: 120g (receiver + antenna array) - Power Consumption: 3W - Constellations: GPS, Galileo, GLONASS, BeiDou, NavIC - Frequencies: L1/L5 or L1/L2 - Interference Resistance: Single jammer up to 90 dB (J/S)

Electric motor used to drive the joint (ST axis) of the Explosive Ordnance Disposal (EOD) Robot.

This miniaturized system allows, depending on the desired configuration, to move very precisely between 1 and 3 sets of lenses over a stroke of several centimeters. The design has been optimized to ensure perfect alignment of the lenses and to minimize their tilt throughout the movement. This optomechanical system mainly consists of high-precision standard MPS and FAULHABER modules, such as brushless or stepper motors, ground ball screws with double nuts and linear ball bearings. It is particularly recommended for focusing a laser over a long distance, for example for the guidance of unmanned flying objects or for communication between flying objects. The number of lens sets, lens size and stroke can be configured at will.

Applied for the Localization Development Project of Core Components in Weapon Systems Conducted basic design for the development for mechanical Mine Sweeping Equipment for MSH, followed by submission of a proposal and presentation for in-person evaluation Patent : Mine Sweeping System with loT Based Functional Float

A cost-effective and reliable EO/IR solution designed for unmanned platforms, combining compact design with strong performance. The system integrates QVGA/VGA-class infrared sensors and 2–20 megapixel EO cameras, providing versatile options to meet different operational requirements. o Infrared (IR) Sensor: QVGA/VGA resolution, optimized for detection and recognition in short-to-mid range surveillance o Electro-Optical (EO) Module: 2MP–20MP visible light cameras with high-resolution imaging, adaptable to multiple mission profiles o Design Philosophy: Lightweight, compact, and robust for integration into unmanned aerial vehicles (UAVs), unmanned surface vehicles (USVs), and ground robotics o Key Value: Balances price competitiveness, system reliability, and modular scalability for mass deployment

Orbit’s TT&C ground stations antenna must function flawlessly in order to provide a narrow beam width link in one-time single opportunity, flight test event. Add this factor to the turbulent weather that is often present at the ground station locations, and you are looking at a formidable hurdle. Orbit provides fixed, transportable, and portable antenna systems that feature auto-track, RSSI-track and GPS track tracking modes, unsurpassed tracking accuracy and durability to deliver the stable connection required for dependable data throughput. Our stabilized T&T antenna systems work in extreme temperature conditions (-40°C to 55°C) and in rough weather, for example, at base stations that are close to the ocean or on high mountain ranges.

Phased Array Multi Function Antenna including Radome
