The Integrated Weather Observation System (IWOS®) is the compact, wireless, rugged weather station that can be customized to any customers’ specific needs. This system can replace legacy weather stations that require hardline power or extensive infrastructure for permanent installation. It integrates up to eight environmental sensing modules with optional satellite communication in a package that fits into a single case and weighs less than 25 lb. In addition to its portability, performance, and professional-grade construction, the modular design of the IWOS lends itself to higher accuracy, higher availability, and a lower lifecycle cost thanks to its easily replaceable and serviceable modules.

Localization development in progress for general components of Tank

Engine accessories for Model 250 Rolls-Royce (Allison) gas turbine engines. Bleed Valves, Fuel Controls, Fuel Nozzles, Fuel Pumps, Governors & more.

Consists of a Data Transmission and Recording Unit (DTRU) for data transmission and collection, and a Removable Mass Memory (RMM) for data storage. Stores pre-planned flight mission data in the RMM on the ground and transmits it to the aircraft via the DTRU. Collects various mission data (flight data, monitoring data, video data, and audio data) during flight, stores it in the RMM, and transmits it to the ground for mission analysis. - x5 ARINC-818 Recording as H.264 - x2 Analog audio recording - x7 MIL-STD-1553B Bus Monitoring - x2 Gigabit Ethernet Monitoring - 512GB Solid-State Disk (up to 2TB) - Size : 160.1x146.0x232.4 mm - Weight : 4.25Kg - Power : MIL-STD-704F (28VDC, 58W) - Environment: MIL-STD-810G - EMI/EMC: MIL-STD-461G

INCONEL® Alloy 230 Bars-Sheets and Plates INCONEL® Alloy 600 Bars-Sheets and Plates-Wire-Tubes and Pipes INCONEL® Alloy 601 Bars-Sheets and Plates-Wire-Tubes and Pipes INCONEL® Alloy 617 Bars-Sheets and Plates INCONEL® Alloy 625 Bars-Sheets and Plates-Tubes and Pipes INCONEL® Alloy 718 Bars-Sheets and Plates INCONEL® Alloy X-750 Bars-Sheets and Plates INCONEL® Alloy HX Bars-Sheets and Plates-Tubes and Pipes NIMONIC® Alloy 75 Bars-Sheets and Plates NIMONIC® Alloy 80A Bars-Sheets and Plates NIMONIC® Alloy 90 Bars-Sheets and Plates-Wire-Strip NIMONIC® Alloy 263 Sheets and Plates UDIMET® Alloy 188 Bars-Sheets and Plate UDIMET® Alloy L-605 Bars-Sheets and Plates Waspaloy® Sheets and Plates

Wing shells, side shells and fuselage sections are usually made of carbon fibre composites and glued together during the production process. With many components, a groove or an open edge remains after the bonding process, which must be filled or sealed. A modified two-component epoxy resin is often mixed and then applied manually. This often entails long production times and complex quality controls. Equally high material costs due to the processing of materials from cartridges. ViscoTec defies short pot life and materials that are difficult to handle: Thanks to a coherent overall system from material removal to material application, this process can be automated. The two components are taken separately from cartridges, hobbocks or drums and fed via hose lines to a two-component dosing system. Only at the very end of the process they are mixed in a static mixing tube and applied to the substrate (e.g. via a nozzle). The process is controlled and monitored by pressure sensors.

It is commonly used in industrial and other devices to generate triggers ranging from one to several thousand FPS, ensuring precise timing synchronization with various devices. Periodic Mode: Continuously generates trigger signals after configuration. Burst Mode: Generates a single trigger signal upon receiving the best command via serial communication. *** Product Expansion and Usage ***  Four Operating Modes  Periodic mode: Generates a single-cycle signal based on the configured frequency and duty ratio.  Burst mode: Generates a single-cycle signal synchronized with a software trigger.  External trigger mode: Generates a single-cycle signal synchronized with an external trigger.  External trigger bypass mode: Distributes signals triggered externally.  Connect the trigger output signals from a Master Trigger Generator to a Slave Trigger Generator (as shown below).  By connecting one of the Master TG’s Trigger Outputs (1 to 16) to the Slave TG’s External Trigger Input: Outputs 1 to 15 of the Master TG remain unchanged. Outputs 16 to 31 of the Slave TG will mirror the Master TG’s Trigger Output. (Note: Each trigger signal passing through a TG experiences a delay of ten ns. However, since trigger outputs operate in the range of tens to thousands of Hz, users will not notice the delay).  Example with 17 TGen-16C units: Produces up to 256 Trigger Output Channels (16 × 16).
