WPGM0811100M is a 100W Gallium Nitride (GaN) Monolithic Microwave Integrated Circuit (MMIC). WPGM0811100M is useful for high power X-band Radar applications. Spec Frequency : 8-11GHz Saturated Output Power : 100W@9.5GHz PAE : 38.7% Power Gain : 29.5dB@9.5GHz Operating Voltage : 28-32V

The new Super-TAC IMU integrates three fiber optic gyros that exceed tactical grade performance with three high-accuracy Micro-Electro-Mechanical Systems (MEMS) accelerometers and state-of-the-art support electronics in a single small, lightweight package. This solution addresses the need for superior inertial performance in a tactical- grade package, critical for operation in GPS denied and contested environments. The Super-TAC IMU measures change in velocity and angle, utilizing a configurable variable synchronous data link control (SDLC) digital serial bus. The Super-TAC is configured to offer customers the best value solution when designing new systems as well as provide the flexibility to upgrade existing platforms. The Super-TAC IMU employs state-of-the-art optics with fewer components, providing significant performance and reliability improvements across standard military environments. Background Emcore, located in Budd Lake, NJ has been designing, developing and producing inertial components, sensors and navigation systems for Space, Ground, and Avionic applications for over 35 years. Emcore has been developing Fiber Optic Gyros (FOGs) since the early 1990s, producing and delivering IMU products with performance ranging from tactical to strategic grade PERFORMANCE GYRO PERFORMANCE Bias Stability < 0.05 °/hr. (1σ) Angle Random Walk ( ARW) ≤ 0.01 °/√hr. (1σ) Scale Factor Repeatability ≤ 100 ppm (1σ) Scale Factor Linearity ≤ 50 ppm (1σ) Angular Rate Range 1,000 °/sec Acceleration Range 100,000 °/sec2 ACCELEROMETER PERFORMANCE Range ± 25 g Bias Variation ≤ 50 μg (1σ) Scale Factor Stability ≤ 300 ppm (1σ) SYSTEM PERFORMANCE Bandwidth (adjustable) 800 Hz (gyros) 150 Hz (accelerometers) MTBF >25,000 hr.

Our firm offers end-to-end GaN production capabilities, including fabrication, packaging, test, and failure analysis to meet custom requirements. To enable customer designs, a process design kit (PDK) is available with a design manual, sample layouts, and a non-linear device model. Options available include fabrication of customer-designed wafers (“PDK foundry service”) or custom design by TransEON and fabrication according to customer specs (“NRE foundry service”). For either option, volume levels available include pilot/engineering runs, multi-project wafers (MPWs), or full production runs.

Patrol Killer Guided Electro Optic Target System

PTO SHAFT, Proven Performance, Realized in Reality CTLA's Power Transmission Shaft (PTO-shaft) is a key component of the aircraft secondary powertrain, transmitting the high-speed rotational power generated by the aircraft engine drive unit (EMAD) to the gearbox (AMAD). By applying high-strength, lightweight titanium material for the first time in the world, we have achieved both weight reduction and durability, while implementing outstanding stability and reliability through our proprietary electron beam welding technology optimized for high-speed rotation and high-speed precision balancing technology. In particular, this product, which is currently being mass-produced and delivered to the KF-21 fighter jet, has demonstrated excellent power transmission performance while minimizing vibration even in extreme environments. CTLA is leading technological innovation in the field of high-speed rotational machinery, spearheading the self-reliance of domestic aircraft components and advancing into the global market.

SJP’s connector components are designed and manufactured to meet the highest standards of precision and reliability across industries. Equipped with state-of-the-art CNC multi-tasking machines and extensive know-how, we deliver solutions ranging from fine threading to complex geometries. Our connectors are widely applied in electronics, medical devices, aerospace, and defense, where durability and stable connectivity are critical. Through customized design services and fast lead times, we help our clients enhance their product competitiveness.

Hermetic connectors are a special class of sealed Mil /Aero interconnect that incorporates glass-to-metal or other highly-engineered sealing technology. Hermetic seal connectors are specified for applications as divergent as submarines and orbiting satellites. They are deployed to resist moisture ingress in underground applications and to withstand pressure differentials in vacuum chambers, laboratory equipment and commercial and military aircraft. Hermetic seal connectors, such as the MIL-DTL-38999 Series I, II, III and IV supplied by Glenair, are principally designed for use in military aerospace — in fact, the sealing requirement for connector hermeticity was originally driven by military electronic applications. But the products are equally at home in commercial applications such as oil-patch, logging equipment or medical devices.

The SCFAN-CTRL-10U is an internal fan control module installed inside the chassis to provide advanced cooling control and system thermal management. It integrates with FAN trays and operates through Kontron’s Power Supply Control Module (PSCM), supporting up to two 12V @ 3.5A fans and seven 12V @ 2.5A fans. This module ensures stable cooling performance and system reliability for high-density VPX-based embedded systems. It is deployed in the M-SAM-II multi-function radar system, where it provides precise and efficient cooling control for mission-critical radar operations.
