Ultra-High Accuracy MEMS Motus features some of the highest accuracy MEMS accelerometers and gyroscopes currently available. Motus’s inertial performance exceeds some FOG IMUs and is up to 100x smaller and 10x cheaper. Motus is put through Advanced Navigation’s intensive calibration process to provide consistently accurate data over an extended temperature range of -40°C to 85°C. Miniature Package Never before has such high inertial performance been available in such a small package. Motus consumes just over 1 cubic inch in volume and weighs only 26 grams. This makes it ideal for weight and size sensitive applications. Motus is available in an OEM package suitable for integration into larger products or an enclosed package for external and standalone use. Advanced Signal Processing Motus samples its sensors synchronously at 1000Hz through six individual 24-bit differential ADCs which minimizes noise as well as providing optimal thermal calibration and performance characteristics. 14 separate heavily filtered regulated power supplies ensure that each sensor and ADC is operating off the cleanest possible power supply. Reliability Motus has been designed from the ground up for mission critical control applications where reliability is very important. It is built on top of a safety oriented real time operating system and all software is designed and tested to safety standards with fault tolerance in mind. The hardware is designed and manufactured to mil standards. High Update Rate Motus outputs temperature calibrated sensor data at 1000Hz as well as filtered attitude at the same rate. This allows for control of dynamically unstable platforms.

• Toggle switches • Circuits breakers • Illuminated push buttons • Relays / Relays bases. • Potentiometer.

Expert sourcing and pricing Cost modeling: Cost per Flight Hour, FFP, EEQ Import/Export classification: ECCN, ITAR, Schedule B Logistics and supply chain analysis Technical review of parts lists and breakdowns Source development and sustainment

This product supports the following transmission standards. Designation Bit Rate ========== ========== CXP-1 1.250 Gbps CXP-2 2.500 Gbps CXP-3 3.125 Gbps CXP-5 5.000 Gbps CXP-6 6.250 Gbps CXP-12 12.500 Gbps The CXR-2C amplifies and transmits image signals from 1/2-channel CoaXPress cameras to a PC frame grabber. Typically, transmission matches the distance between the camera and the device. Transmission distance depends on the coaxial cable type, and due to significant variability, specific distances are not provided.

BAE Systems is bringing together decades of demonstrated cross domain know-how and expertise in integrated flight controls and propulsion solutions to enable the next generation of aircraft. We are investing in the development of highly reliable, flight and safety critical systems that will enable the future of hybrid and all-electric aircraft.

Missions is the only commercially available analysis tool which brings together aircraft definition, aircraft performance and cost investigations in a single environment and delivers reliable projections of key metrics such as payload capacity, maximum range and direct operating cost. Excellent runtime performance and the integrated analysis environment ensure fast results even when dealing with large route networks.

The Fibre Channel D-sub connector series features a multi-finger ground spring fixed around the shell provides a multi-point contact engagement that affords superior EMI shielding. The end result is extremely low contact resistance when measured from the contact outer body to the connector flange. The Fibre Channel D-Sub series also delivers superior performance ensuring minimal RF noise and high durability up to 1,000 mating cycles, while meeting and surpassing all requirements of MIL-STD-202 for shock and vibration. Offered with 150 Ohm quadrax contacts, the connectors are available with 2, 4, 6 or 8 way insert arrangements. Additionally, D-Sub connectors feature ease of assembly, and a robust and comprehensive training package. To ensure that the correct high speed connectors are mated to address specific wiring requirements and keying functions, a keyed jack post option has been incorporated into the design. The six-positioned post allows for 36 possible keying combinations assuring that the correct Fibre Channel D-Sub plug is mated to the correct high speed receptacle. Non-keyed jack post versions are available as well. Fibre Channel D-Sub connectors feature size 3 quadrax contacts which are 30% larger than the size 9 configuration utilized in the 100 Ohm quadrax, ensuring a matched impedance signal throughout the contact mated pair at 150 Ohm differential impedance. These features ensure that Smiths Interconnect's Fibre Channel D-Sub connectors deliver the critical edge customers require.

Brazing is bonding two or more pieces of metal by means of flowing a filler metal between the joint interfaces at a temperature below the melting point of the base metal. The filler metal, upon cooling to the solid state, forms a strong metallic bond throughout the joined area. Through Dip-Brazing, RF Systems manufacture 1. Brazed Antennas 2. Brazed Waveguides 3. Brazed Divider / Combiner
