The UHF-band TRX module features transmit diversity, allowing selection between two transmit ports and providing an output power of at least 1 W. It includes a gain control function for transmission and an internal local oscillator for IF-to-UHF upconversion. Transmit functions also include ALC (Automatic Level Control) and over-temperature protection. On the receive side, the module selects one of two input channels and performs downconversion. It supports AGC (Automatic Gain Control) with a response time of 80 µs, enabling real-time gain adjustment based on input signal level. The dynamic range of the receive input spans from -100 dBm to -20 dBm, and the noise figure is 5.0 dB or less. Both transmit and receive paths include built-in path self-test functions.

The M109A7 is the latest howitzer in the BAE Systems M109 family of vehicles, the primary indirect fire support system for the ABCTs. It uses the existing main armament and cab structure of a Paladin M109A6, and replaces the vehicle’s chassis components with modem components common to the Bradley vehicle. The improved chassis structure provides greater survivability and commonality with the existing systems in the ABCT, reducing operational sustainability costs by replacing obsolete components. The M109A7 is supported by the Army as a vital technology enhancement program to maintain the combat capability of its ABCTs. The M109A7 will solve long-term readiness and modernization needs of the M109 family of vehicles through a critical redesign and production plan that leverages the most advanced technology available today. This state-of-the-art “digital backbone” and power generation capability provides a more robust, survivable and responsive indirect fire support capability for ABCT Soldiers. The M109A7 is considered to be the most cost-effective method to significantly improve sustainability and survivability, while reducing the logistics burden on the ABCT and supporting fires brigades. The program will be executed as a public/private partnership between the Army’s Project Manager-HBCT, Anniston Army Depot and BAE Systems that leverages the strengths of both public and private sectors to ensure the best value for U.S. Soldiers.

ALTERNATIVES TO: MS25271 / MS25395 / MS25267 / MS25269 / MS25273 / MS27418

A sleeve in military or aerospace applications is a protective covering used for wiring harnesses and cables

- Integrated control of two zones: engine bay and crew bay - Equipped with a self-diagnostic function for key AFSS components - Capable of interfacing with the vehicle computer - Adjustable temperature setting for engine bay fire detection

1. Filler Metal Name Material/Alloy AWS W-No. ISO-No. Nickel 61 Ni A5.14 ERNi-1 2.4155 SiNi2061 MONEL® 60 Ni-Cu A5.14 ERNiCu-7 2.4377 SNi4060 MONEL® 67 Cu-Ni A5.7 ERCuNi 2.8037 SCu7158 INCONEL® 72 Ni-Cr A5.14 ERNiCr-4 SNi6071 NC 80/20 Ni-Cr 2.4639 INCONEL® 82 Ni-Cr A5.14 ERNiCr-3 2.4806 SNi6082 INCONEL® 622 Ni-Cr-Mo A5.14 ERNiCrMo-10 SNi6022 INCONEL® 625 Ni-Cr-Mo A5.14 ERNiCrMo-3 2.4831 SNi6625 INCO-WELD® 686-CPT Ni-Cr-Mo A5.14 ERNiCrMo-14 SNi6686 INCO-WELD® 725NDUR Ni-Cr-Mo A5.14 ERNiCrMo-15 SNi7725 INCO-WELD® C-276 Ni-Cr-Mo A5.14 ERNiCrMo-4 2.4886 SNi6276 INCONEL® 52 Ni-Cr-Fe A5.14 ERNiCrFe-7 SNi6052 INCONEL® 52M Ni-Cr-Fe A5.14 ERNiCrFe-7A INCONEL® 92 Ni-Cr-Fe A5.14 ERNiCrFe-6 SNi7092 INCONEL® 617 Ni-Cr-Co-Mo A5.14 ERNiCrCoMo-1 2.4627 SNi6617 NILO® CF36 Ni-Fe INCOLOY® 65 Ni-Fe-Cr A5.14 ERNiFeCr-1 SNi8065 INCONEL® 718 Ni-Fe-Cr A5.14 ERNiFeCr-2 2.4667 SNi7718 Titanium Grade 1 Ti A5.16-90 ERTi-1 Titanium Grade 2 Ti A5.16-90 ERTi-2 Titanium Grade 5 Ti-Al-V A5.16-90 ERTi-5 Titanium Grade 7 Ti-Pd A5.16-90 ERTi-7 2. Electrodes Name Material/Alloy AWS W-No. ISO-No. Nickel 141 Ni A5.11 ENi-1 2.4156 ENi2061 MONEL® 190 Ni-Cu A5.11 ENiCu-7 2.4366 ENi4060 MONEL® 187 Cu-Ni A5.6 ECuNi 2.0838 ECu7158 INCO-WELD® A Ni-Cr-Fe A5.11 ENiCrFe-2 2.4805 ENi6092 INCONEL® 152 Ni-Cr-Fe A5.11 ENiCrFe-7 ENi6152 INCONEL® 182 Ni-Cr-Fe A5.11 ENiCrFe-3 2.4807 ENi6182 INCONEL® 112 Ni-Cr-Mo A5.11 ENiCrMo-3 2.4621 ENi6625 INCONEL® 122 Ni-Cr-Mo A5.11 ENiCrMo-10 ENi6022 INCO-WELD® C-276 Ni-Cr-Mo A5.11 ERNiCrMo-4 2.4887 ENi6276 INCO-WELD® 686CPT Ni-Cr-Mo A5.11 ERNiCrMo-14 ENi6686 INCONEL® 117 Ni-Cr-Co-Mo A5.11 ERNiCrCoMo-1 2.4628 ENi6617

STANAG 4695 & GOSSRA* * GENERIC OPEN SOLDIER SYSTEM REFERENCE ARCHITECTURE compatible with Nett Warrior BREAK-AWAY CONNECTOR

ㅇKey Features - User Configurable or Factory Set equipment - Support Single/Multi-Band Configuration - Compact / Low Weight / High Power Efficiency - Clock-Free Input Option Available - RS-422 (DATA±, CLK±), RS-232(DEBUG) ㅇQuality and Certification - IRIG 106 - MIL-STD-810G
