Its compact and robust design, coupled with a choice of analog, digital, and digital RS-232 outputs, makes the DSP-3000 the most versatile fiber optic gyro available and an ideal solution for guidance and stabilization, low-cost IMUs, integrated GPS/INS, and AHRS. Highlights EMCORE’s mature all-fiber optical circuit for exceptionally low noise (ARW) EMCORE’s proprietary E•Core polarization-maintaining fiber Robust, modular design housed in a package roughly the same size as a deck of playing cards Technology Details DSP Technology EMCORE’s DSP electronics improve FOG performance in critical areas such as scale factor and bias vs. temperature, scale factor linearity, and maximum input rate. EMCORE’s exclusive DSP design is covered by multiple patents* and overcomes the limitations of analog signal processing, eliminating temperature-sensitive drift and rotation errors. *This product is covered by one or more patents, including U.S. Patent #6,429,939, “DSP Signal Processing for Open Loop Fiber Optic Sensors.” Feature Options Two Versatile Variants If you need a compact FOG with a powerful high-speed RS-422 interface with 1000 Hz asynchronous output, consider the DSP-3100 FOG. If you require a true RS-422 interface and a 1000 Hz synchronous output in a durable, shielded package, take a look at the DSP-3400.

The X-band LNB is a satellite ground transport terminal that includes a transmission rejection filter and performs downconversion of X-band signals to IF using an internal reference frequency. It features dustproof, moisture-proof, and waterproof protection, along with self-diagnostic functions such as a lock alarm. The unit provides a total gain of over 60 dB and supports a wide bandwidth of 500 MHz. Its frequency stability is maintained within 0.31 ppm.

Ultra-High Accuracy MEMS Motus features some of the highest accuracy MEMS accelerometers and gyroscopes currently available. Motus’s inertial performance exceeds some FOG IMUs and is up to 100x smaller and 10x cheaper. Motus is put through Advanced Navigation’s intensive calibration process to provide consistently accurate data over an extended temperature range of -40°C to 85°C. Miniature Package Never before has such high inertial performance been available in such a small package. Motus consumes just over 1 cubic inch in volume and weighs only 26 grams. This makes it ideal for weight and size sensitive applications. Motus is available in an OEM package suitable for integration into larger products or an enclosed package for external and standalone use. Advanced Signal Processing Motus samples its sensors synchronously at 1000Hz through six individual 24-bit differential ADCs which minimizes noise as well as providing optimal thermal calibration and performance characteristics. 14 separate heavily filtered regulated power supplies ensure that each sensor and ADC is operating off the cleanest possible power supply. Reliability Motus has been designed from the ground up for mission critical control applications where reliability is very important. It is built on top of a safety oriented real time operating system and all software is designed and tested to safety standards with fault tolerance in mind. The hardware is designed and manufactured to mil standards. High Update Rate Motus outputs temperature calibrated sensor data at 1000Hz as well as filtered attitude at the same rate. This allows for control of dynamically unstable platforms.

The Haigh-Farr Wraparound™ is a self-contained omnidirectional antenna for cylindrical or conical shaped bodies. A single point feed is used and no external splitters, combiners or cable harnesses are required for installation. The antenna is conformal, and may be mounted flush, or on the exterior of the vehicle. Designs are available from 300 MHz to 13 GHz with typical applications including Flight Termination, GPS, Telemetry, Data Links and Transponder. Multiple antenna elements may be combined within the same physical Wraparound™, providing multi- band capability in a single, compact package. Wraparound™ antennas have been flown on vehicles from subsurface sea to space, including high-mach kinetic kill weapons, high-G projectiles and re-entry vehicles. The Wraparound™ has been qualified for use on several high performance vehicles flown on test and launch ranges throughout the United States and Europe. For high aero-heating applications an ablative heat shield may be added to the antenna for additional thermal protection.

We carry a wide range of aerospace-grade materials in round bar and sheet, including: -Alloy 718 (AMS5596) -Alloy 625 (AMS5599) -Alloy X (AMS5536) There is no minimum order quantity ? we can cut from a single piece and ship within 1?2 days, complete with full material traceability. For non-stock grades, shapes, and standards, we can source materials from suppliers worldwide with a lead time of approximately 2 weeks, also with no minimum order quantity.

ALTERNATIVE TO M19648/1 SERIES

The SBC6511 Rugged Single Board Computer(SBC) from Abaco Systems features the new high performance, highly integrated Intel® Xeon® E processor (‘Coffee Lake Refresh’). Powered by Intel® Xeon® W processors, offering robust computational power. • Supports up to 64 GB DDR4 SDRAM with ECC and up to 256 GB (or in some variants up to 480 GB) NVMe SSD storage • Offers high-throughput networking: Dual 40 GbE data-plane (KR4 “fat pipes”) • Features the Xilinx® Zynq® UltraScale+™ MPSoC FPGA (ZU7EG) for enhanced security

This rocket nozzle featuring conformal cooling channels and isogrid ribbing was manufactured using EOS Copper CuCP, a pure copper material optimized for additive manufacturing. The production required approximately 72 hours, taking advantage of the exceptional thermal and electrical conductivity of pure copper to meet demanding aerospace performance requirements. As one of the few companies in Korea capable of performing metal additive manufacturing with pure copper, we provide advanced technical expertise and support OEM production as well as collaborative technology development projects with various industrial partners. The showcased component was designed by nTopology and demonstrates the synergy of advanced design optimization with state-of-the-art copper additive manufacturing.
