Maximum Control for your interactive graphical displays. Developing HMIs for safety- and mission-critical avionics and embedded displays only gets more demanding. VAPS XT offers HMI designers, systems engineers, and embedded engineers maximum control and flexibility for creating interactive real-time graphical displays for avionics and other safety-critical embedded applications. With an open architecture and integrated logic capabilities, VAPS XT provides the essential features for the design and deployment of certifiable cockpit displays. VAPS XT provides a model-based environment supporting all phases of development from initial concept to embedded deployment. Through a flexible porting structure, VAPS XT applications can be easily deployed to virtually any embedded target with excellent performance.

A wire in military or aerospace applications is a conductor used to transmit electrical power or signals between components in aircraft, vehicles, or defense systems.

1. Integrate the most effective aspects of Visible and IR(Infrared) image. 2. Increase the efficiency through the ability to use in all weather conditions, day or night, including fog.

Featuring an ultra-compact package of less than 5 cubic inches, the TAC-440 delivers 1°/hour gyro bias with 1 mg accelerometer bias stability and very low 0.05°/√hour angle random walk (ARW) over wide temperature ranges. The breakthrough performance of the TAC-440 IMU is based on a EMCORE’s proven quartz MEMS inertial sensor technology. EMCORE’s quartz technology enables repeatable, high-volume production of precisely machined sensor structures combined with the inherent large signal output and thermal stability of quartz materials. The TAC-440 is a compact IMU constructed with EMCORE’s latest generation quartz gyros, quartz accelerometers, and high-speed signal processing to achieve outstanding precision performance. The TAC-440 IMU is designed for demanding, mission-critical, rugged environments. The solid-state quartz sensors and hermetically sealed IMU construction provide reliable MTBF. Continuous Built-in Test (BIT), configurable communications protocols, electromagnetic interference (EMI) protection make the TAC-440 IMU easy to use in a wide range of higher order integrated system applications.

Threaded bushing enables localized reinforcement of and attachment to panel structure. Supplied with disposable installation fixture. 1.25" Flange Diameter. SIZES: Imperial fine thread sizes from 10-32 (.190"-32) to 3/8-24 (.375"-24), Imperial coarse thread sizes from 8-32 (.164"-32) to 3/8-16 (.375"-16), and metric thread sizes from M5 to M8. 1.25" Flange Diameter. Grip lengths from 0.25" to 1.50". MATERIALS: Aluminum, 300 Series Stainless Steel, A-286 Stainless Steel, 316 Stainless Steel, and Titanium. Optional epoxy primer. FEATURES: Standard 1.25" diameter flange, 0.75" x 1.25" trimmed flange optional.

The SDI170 IMU is designed for demanding, mission-critical, rugged environments and ideal for continuous use applications with no wear-out components, highly linear accelerometer performance and longer life compared to competing alternatives. It is constructed with EMCORE’s latest generation quartz gyros, quartz accelerometers, and high-speed signal processing to achieve outstanding precision performance. The solid-state quartz sensors and hermetically sealed IMU construction provide reliable MTBF and a 20-year operating and storage life. Continuous Built-in Test (BIT), configurable communications protocols, electromagnetic interference (EMI) protection and flexible input power compatibility make the SDI170 IMU easy to use in a wide range of higher-order integrated commercial and defense system applications.

This product supports the following transmission standards. Designation Bit Rate ========== ========== CXP-1 1.250 Gbps CXP-2 2.500 Gbps CXP-3 3.125 Gbps CXP-5 5.000 Gbps CXP-6 6.250 Gbps CXP-12 12.500 Gbps The CXR-2C amplifies and transmits image signals from 1/2-channel CoaXPress cameras to a PC frame grabber. Typically, transmission matches the distance between the camera and the device. Transmission distance depends on the coaxial cable type, and due to significant variability, specific distances are not provided.

The KX2-2046 is an X-band high-power MMIC amplifier fabricated on the GaN-on-SiC process. It operates from 8.0 – 10.5 GHz and typically provides 20W saturated output power with power-added efficiency of 46%. The KX2-2046 can support military and commercial radar systems. It is matched to 50Ω with integrated DC blocking capacitors on both RF input and output ports. The KX2-2046 is 100% DC and RF tested on-wafer. It is available in chip form. **Key Features** - Frequency Range: 8.0-11.5GHz - Small Signal Gain: 26dB - High Pout: 20W - High PAE: 46% - DC bias: Vd=28V @Idq=0.3A - Pulsed Vg: PW=100µs, DC=10% - Chip size: 2.95x1.66x0.1mm
