Altimeter for Missile Application

ICONYX™ is a high-performance tactical grade Inertial Measurement Unit (IMU) for guidance and control applications. ICONYX™ is designed to meet the most demanding environmental conditions with extreme accuracy and reliability. Proven Technology Safran proposes an IMU based on Hemispherical Resonator Gyroscope the HRG Crystal™. This technology is combat proven for 15 years and is extremely accurate, reliable, and is capable of navigating in the most contested GNSS denied environments. HRG Crystal™ Embedded Thanks to the HRG Crystal™, ICONYX™ surpasses the highest performances of its category while keeping the best in class SWaP (Size, Weight, and Power) characteristics of the market. High performance in demanding environments ICONYX™ includes 3 hemispherical resonator gyroscopes HRG Crystal ™ and 3 closed loop MEMS (Micro Electro Mechanical Systems) accelerometers in a compact package. Both Safran’s gyroscopes and Safran’s accelerometers are technological breakthrough.

Sierra Nevada Corporation is a provider of secure computing and communications solutions, enabling high-speed, high-capacity voice, data and video communications for the Department of Defense (DoD) and other mission partners.

The UHF-band TRX module features transmit diversity, allowing selection between two transmit ports and providing an output power of at least 1 W. It includes a gain control function for transmission and an internal local oscillator for IF-to-UHF upconversion. Transmit functions also include ALC (Automatic Level Control) and over-temperature protection. On the receive side, the module selects one of two input channels and performs downconversion. It supports AGC (Automatic Gain Control) with a response time of 80 µs, enabling real-time gain adjustment based on input signal level. The dynamic range of the receive input spans from -100 dBm to -20 dBm, and the noise figure is 5.0 dB or less. Both transmit and receive paths include built-in path self-test functions.

Using a data storage module and a series of high-speed switches, our solution offers expandable memory up to 64 TB and high-speed processing power. Along with our attendant control panel, designed to reduce the crew's workload, we offer a complete end-to-end solution.

Processor - NXP Quad Core PowerPC QorIQT2080 up to 1.8GHz - 6 DMIPS/MHz per core (up to 43,200 DMIPS@1.8GHz) - 128b AltiVecSIMD unit (up to 72 GFLOPs@1.8GHz) Memory - 4GB soldered 64-bit DDR3L SDRAM with ECC - 256MB 16-bit NOR flash - 64GB SATA NAND SSD - 512KB NvRAM Form Factor - 3U OpenVPX - Conduction-Cooled

The 100W High Power Amplifier is an L-band amplifier that delivers 100W output across two channels with a 60% duty cycle. It offers a gain of over 50 dB, with output flatness of 2 dB depending on the input signal level. The amplifier provides an ACLR performance of -20 dBc at maximum output. Equipped with an output-stage bandpass filter (BPF), it achieves excellent harmonic suppression of -70 dBc. Built-in monitoring functions include output signal and temperature monitoring.

We are an EASA-certified APU manufacturer. To date, we have installed more than 7,000 PBS APUs. This APU includes completely new combustion chamber, new control unit allowing allow non-operating altitude up to 8,000 m AMSL. Redesigned fuel system. Continuous operation for 6 hours. Exceptional reliability. Start up to 6,000 m
